Read temperature and humidity with the DHT11

Connect the DHT11 sensor module to the ESP32 and print the room temperature and humidity every two seconds.
  • Level:Beginner
  • Duration: 40 min
  • Ages 12+
  • Platform: ESP32

What you'll need

Tools for this lesson

Helpful for this build. Open a tool to see tips and more projects that use it.

Read temperature and humidity with the DHT11 – EEMENTOR STEM™ lesson

The DHT11 measures both temperature and humidity and sends the result over a single data wire. It's the heart of weather stations, greenhouse monitors and smart thermostats.

What you'll learn

  • How to install a library with the Library Manager
  • How to read a digital sensor
  • How to handle a failed reading

What you need

  • ESP32-DevKitC V4 board and USB cable
  • DHT11 temperature and humidity module (KY-015)
  • Breadboard
  • 3 jumper wires

Step 1: Install the library

Open Tools → Manage Libraries, search for DHT sensor library and install the one by Adafruit. When asked, also install its dependency, Adafruit Unified Sensor.

Step 2: Wiring

The module has three pins. Check the labels printed on your module: usually S (signal), the middle pin (power) and - (ground).

Breadboard wiring diagram: Read temperature and humidity with the DHT11
Breadboard view. Check each connection against the wiring table below.
DHT11 module pin ESP32 pin
S (signal) GPIO 27
Middle (+) 3V3
- (ground) GND
FREE

Build this circuit in EEMENTOR Lab

Wire it yourself in your browser before you touch a real wire. No sign-up, nothing to install.

The ESP32 and the parts for this lesson laid out in EEMENTOR Lab, ready to wireBuild it yourself
  1. The ESP32 and this lesson’s parts are already placed. Wire them using the wiring table above. Pins with no wire show red.
  2. Missing a part? Add it from the parts list on the left.
  3. Press Run, then try the inputs: click, hold or slide them under Selected.
  4. Then try this lesson’s sketch: paste it into the Code tab and press Compile & Run.

EEMENTOR Lab is free and in beta. Results are a guide; a real build can differ slightly. About the Lab

Step 3: The sketch

#include <DHT.h>

const int DHT_PIN = 27;
DHT dht(DHT_PIN, DHT11);

void setup() {
  Serial.begin(115200);
  dht.begin();
}

void loop() {
  delay(2000); // the DHT11 needs about 2 seconds between readings

  float humidity = dht.readHumidity();
  float temperature = dht.readTemperature(); // Celsius

  if (isnan(humidity) || isnan(temperature)) {
    Serial.println("Couldn't read the sensor, check the wiring");
    return;
  }

  Serial.print("Temperature: ");
  Serial.print(temperature);
  Serial.print(" °C   Humidity: ");
  Serial.print(humidity);
  Serial.println(" %");
}

How it works

The library asks the sensor for a reading, and the sensor answers with a short burst of pulses on the data wire. If something goes wrong, the library returns NaN ("not a number"), which the sketch checks with isnan(). The DHT11 is accurate to about ±2 °C and ±5 % humidity, which is fine for a room monitor.

Try this next

  • Breathe gently on the sensor and watch the humidity rise.
  • Add the LED from lesson 1 and switch it on when the temperature goes above 26 °C.

Troubleshooting

  • "Couldn't read the sensor": check that S is on GPIO 27 and the power pins aren't swapped.
  • Compile error about DHT.h: the library isn't installed. Repeat step 1.
