Build quiz buzzers for two players

In a quiz, the hardest part is often deciding who was first. Let the UNO decide! Each player has a buzzer: one is the touch sensor from the sensor kit, the other is the button module. The first to press gets their light and a beep, and the other buzzer is locked. Then the quiz master uses one button: a short press means "wrong, the other player may try", a long press means "right, one point". The scores appear in the Serial Monitor.

What you'll learn

• How to check two inputs often enough that the fastest press always wins
• How a "state" variable controls what a game is waiting for
• How to tell a short press from a long press
• How to lock out a player who has already answered

What you need

• UNO R3 board and USB cable (UNO R3 Starter Kit)
• Touch sensor module (45-in-1 Sensor Kit)
• Button module (45-in-1 Sensor Kit)
• Active buzzer module (45-in-1 Sensor Kit)
• Red and blue LEDs and 2 resistors, 220 Ω (UNO R3 Starter Kit)
• 1 push button for the quiz master (UNO R3 Starter Kit)
• Long female-to-male jumper wires
• The printed parts from the 3D printing box below (buzzer domes), or the cardboard version described there
• Breadboard and jumper wires (UNO R3 Starter Kit)

Wiring

Sensor modules from different makers can label and order their pins differently. Always follow the labels printed on your module.

The sketch

const int PLAYER_PINS[2] = {2, 3};   // touch module, button module
const int LED_PINS[2] = {5, 6};
const int HOST_PIN = 4;
const int BUZZER_PIN = 8;

int rest[2];                 // reading when nobody presses
int score[2] = {0, 0};
bool lockedOut[2] = {false, false};
int answering = -1;          // -1: waiting for a buzz, 0 or 1: that player answers

bool pressing(int p) {
  return digitalRead(PLAYER_PINS[p]) != rest[p];
}

void beep(int ms) {
  digitalWrite(BUZZER_PIN, HIGH);
  delay(ms);
  digitalWrite(BUZZER_PIN, LOW);
}

void printScores() {
  Serial.print("Player 1 (touch): ");
  Serial.print(score[0]);
  Serial.print("   Player 2 (button): ");
  Serial.println(score[1]);
}

void newQuestion() {
  answering = -1;
  lockedOut[0] = lockedOut[1] = false;
  digitalWrite(LED_PINS[0], LOW);
  digitalWrite(LED_PINS[1], LOW);
  Serial.println("--- Next question! ---");
}

// Returns how long the quiz master held the button, in ms (0 = not pressed)
unsigned long hostPress() {
  if (digitalRead(HOST_PIN) == HIGH) return 0;
  unsigned long start = millis();
  while (digitalRead(HOST_PIN) == LOW) {
    if (millis() - start > 800) digitalWrite(LED_PINS[answering], (millis() / 100) % 2);   // blink: "point!"
  }
  return millis() - start;
}

void setup() {
  Serial.begin(9600);
  for (int p = 0; p < 2; p++) {
    pinMode(PLAYER_PINS[p], INPUT);
    pinMode(LED_PINS[p], OUTPUT);
  }
  pinMode(HOST_PIN, INPUT_PULLUP);
  pinMode(BUZZER_PIN, OUTPUT);
  delay(300);
  rest[0] = digitalRead(PLAYER_PINS[0]);
  rest[1] = digitalRead(PLAYER_PINS[1]);
  Serial.println("Quiz buzzers ready.");
  newQuestion();
}

void loop() {
  if (answering < 0) {
    // Read both players in the same moment; the first one to change wins
    bool p0 = pressing(0) && !lockedOut[0];
    bool p1 = pressing(1) && !lockedOut[1];
    if (p0 || p1) {
      answering = p0 ? 0 : 1;          // a real tie (same microsecond) goes to player 1
      digitalWrite(LED_PINS[answering], HIGH);
      beep(300);
      Serial.print("Player ");
      Serial.print(answering + 1);
      Serial.println(" answers!");
    }
    if (digitalRead(HOST_PIN) == LOW) {   // nobody knows: skip the question
      while (digitalRead(HOST_PIN) == LOW) delay(5);
      newQuestion();
    }
    return;
  }

  unsigned long held = hostPress();
  if (held == 0) return;
  if (held > 800) {                     // long press: correct
    score[answering]++;
    beep(80); delay(80); beep(80);
    printScores();
    newQuestion();
  } else if (held > 30) {               // short press: wrong, the other player may try
    lockedOut[answering] = true;
    digitalWrite(LED_PINS[answering], LOW);
    Serial.println("Wrong! The other player may answer.");
    answering = -1;
    if (lockedOut[0] && lockedOut[1]) newQuestion();
  }
}

Play

1. Open the Serial Monitor at 9600 baud and read out a question.
2. The first player to touch or press gets their light. The other buzzer does nothing now.
3. Right answer: hold the quiz master button until the light blinks (about one second). Wrong answer: press it briefly, and the other player gets a chance.
4. If nobody buzzes, a short press on the quiz master button skips to the next question.

How it works

The game is always in one of two states: waiting for a buzz (answering is -1) or waiting for the quiz master (answering is 0 or 1). loop() does something different in each state. Thinking in states like this keeps a game sketch tidy, even when it gets bigger.

While waiting for a buzz, loop() does almost nothing else, so it reads both players many thousand times a second. A human reaction takes around 200 ms, so whoever is first by even a thousandth of a second wins. The lockedOut array remembers who has already given a wrong answer, so they can't buzz again for the same question.

The quiz master's button is timed: hostPress() waits until it is released and returns how long it was held. Over 800 ms counts as a long press. The LED starts blinking at that moment, so the quiz master knows they can let go.

Try this next

• Add a third player with the sensor kit's knock sensor.
• Show the scores on the 1602 LCD instead of the Serial Monitor.
• Give each player 10 seconds to answer, with a countdown beep.

Troubleshooting

• A player wins without pressing: restart the UNO without touching any buzzer, so it learns the resting values.
• The touch buzzer doesn't react: touch the metal plate with your fingertip, and turn the module's screw if needed.
• Long presses count as short ones: hold the button until the LED starts blinking.
• A printed part is too tight or too loose: printers differ by a few tenths of a millimetre. Sand or file a tight hole, and fix a loose part with a drop of hot glue or a strip of tape.
