An RGB LED is really three LEDs in one package: red, green and blue. By changing how bright each one is, you can mix almost any colour, just like the pixels on a screen.
What you'll learn
- What PWM (pulse-width modulation) is
- How to use
analogWrite() - How colours are mixed from red, green and blue
What you need
- UNO R3 board (or any Arduino-compatible board) and USB cable
- RGB LED module from the 45-in-1 kit
- Breadboard
- 3 resistors, 220 Ω
- Jumper wires
Wiring
Check the labels on your module: R, G, B and − (the common ground). A 220 Ω resistor in each colour line protects the LED, even if your module already has resistors on board.

Build it step by step
Plug in all the parts first, then add the wires in this order. In each picture the new wires are bright and the ones from earlier steps are faded. Click a picture to see it larger.
| From | Through | To |
|---|---|---|
| UNO pin 9 | 220 Ω resistor | Module R |
| UNO pin 10 | 220 Ω resistor | Module G |
| UNO pin 11 | 220 Ω resistor | Module B |
| Module − | UNO GND |
Build this circuit in EEMENTOR Lab
Wire it yourself in your browser before you touch a real wire. No sign-up, nothing to install.
Build it yourself
- Wire the parts using the wiring table above. Pins with no wire show red.
- Press Run and watch the LED change colour.
- Then try this lesson’s sketch: paste it into the Code tab and press Compile & Run.
Stuck? See the finished circuit →
EEMENTOR Lab is free and in beta. Results are a guide; a real build can differ slightly. About the Lab
The sketch
const int RED_PIN = 9;
const int GREEN_PIN = 10;
const int BLUE_PIN = 11;
void setColor(int red, int green, int blue) {
analogWrite(RED_PIN, red); // 0 = off, 255 = full brightness
analogWrite(GREEN_PIN, green);
analogWrite(BLUE_PIN, blue);
}
void setup() {
pinMode(RED_PIN, OUTPUT);
pinMode(GREEN_PIN, OUTPUT);
pinMode(BLUE_PIN, OUTPUT);
}
void loop() {
setColor(255, 0, 0); // red
delay(1000);
setColor(0, 255, 0); // green
delay(1000);
setColor(0, 0, 255); // blue
delay(1000);
setColor(255, 255, 0); // yellow
delay(1000);
setColor(0, 255, 255); // cyan
delay(1000);
setColor(255, 0, 255); // magenta
delay(1000);
setColor(255, 255, 255); // white
delay(1000);
}
What you should see

How it works

Pins 9, 10 and 11 support PWM, marked with a ~ on the board. PWM switches the pin on and off very fast, hundreds of times per second. analogWrite(pin, 128) keeps it on about half the time, which your eye sees as half brightness. Mixing red and green gives yellow, green and blue gives cyan, and all three together give white.
Try this next
- Make a smooth rainbow by slowly changing the values in a
forloop. - Combine this with the night light lesson: the darker the room, the bluer the light.
Troubleshooting
- A colour is missing: check that colour's resistor and wire, and that it goes to pin 9, 10 or 11.
-
The colours are inverted (white when it should be off): you have a common-anode LED. Connect its common pin to 5V instead of GND, and use
255 - valueinsetColor().
